Kona Unit X

Kona Unit X
  • Color: Matte Bloodstone w/ Charcoal & Nimbus Decals
  • Color: Matte Bloodstone w/ Charcoal & Nimbus Decals
  • Color: Matte Bloodstone w/ Charcoal & Nimbus Decals
  • Color: Matte Bloodstone w/ Charcoal & Nimbus Decals
  • Color: Matte Bloodstone w/ Charcoal & Nimbus Decals
  • Color: Matte Bloodstone w/ Charcoal & Nimbus Decals
  • Color: Matte Bloodstone w/ Charcoal & Nimbus Decals
$1,599.00
Color: Matte Bloodstone w/ Charcoal & Nimbus Decals
Size: Select size
Please select options Unavailable

Details

The Unit X has become a cult favorite among die-hard Kona fans. Maybe it’s the Cromoly frame. Maybe it’s the fact that it’s a bikepacking monster, or its well-geared 12-speed drivetrain, or modular dropouts which give you the ability to run it as a single speed if that’s your thing. Maybe it’s because the rigid fork makes it that much more of a classic. We may never know why the Unit X is such a popular bike, but we can only guess it’s because it is one of the most practical machines in our lineup.

Reynolds 520 Cromoly
Reynolds 520 tubes are mandrel-butted for accurate profiles and available in a wide range of shapes. Weight savings from butting provides competitively priced, light framesets that are noticeably compliant on the road or the trail, and are guaranteed to last a lifetime.

Internal Headset
Bearing cups are actually pressed into the frame and are easily removable. An internal headset also reduces stack height, so the height of the stem and bars are more adjustable, giving the rider the best fit possible.

44mm Head Tube
44mm oversized heatubes allow us to run tapered steerer forks by using a large external lower cup headset bearing. The larger diameter steerer tube adds considerable stiffness and will increase responsiveness to the front end, improving all-around performance.

Tubeless Compatible Rims
Tubeless rims allow for tires with more puncture resistance; the ability to run lower tire pressure, which provides better tire grip on the trail; lower rolling resistance; and weight savings over traditional tube and tire systems.

12x148mm Axle
12x142mm, 12x148, and 12x157 rear axle standards provide two major advantages to the Kona rider: the 12mm diameter of the rear axle provides the rear hub and frame with a stiff interface, while the 142/148/157mm outer diameter of the hub allows the wheel to be quickly and properly positioned in the frame before the rear axle is inserted.

Specs

Frame Reynolds 520 Butted Cromoly
Fork Kona Plus Fork 110mm spacing
Headset FSA No.1/12B/44
Axles Front: 110 x 15mm thru-axle
Rear: 148 x 12mm thru-axle
Rims/Wheels WTB ST i30 2.0 TCS
Hubs Shimano/Formula
Spokes Stainless Black 14g
Tires Maxxis Rekon TR 29x2.6" or WTB Ranger TCS 29x2.6"
Crankset Prowheel 12spd
Chainrings 32T
Bottom Bracket Prowheel 73mm
Chain Shimano Deore 12spd
Rear Derailleur Shimano Deore
Cassette/Rear Cogs Shimano Deore 10-51t 12spd
Shifters Shimano Deore 12spd
Handlebars Kona XC/BC Riser
Tape/Grips Kona Key Grip
Stem Kona XC/BC
Brake Levers Shimano MT410 Hydraulic
Brakes Shimano MT410 Hydraulic
Saddle WTB Volt
Seat Post Kona Thumb w/Offset 31.6mm

* Subject to change without notice.

Part Numbers

Option Store SKU
Matte Bloodstone w/ Charcoal & Nimbus Decals / Small 210000038006
Matte Bloodstone w/ Charcoal & Nimbus Decals / Medium 210000036422
Matte Bloodstone w/ Charcoal & Nimbus Decals / Large 210000036423
Matte Bloodstone w/ Charcoal & Nimbus Decals / X-Large 210000036424
